Description
The Öhlins Road & Track Coilovers for the 2017+ Honda Civic Type R are a 1-way adjustable high performance suspension setup for drivers seeking nothing less than the best. The Road&Track feature DFV (Dual Flow Valve) Technology, a thermal expanding needle bleed valve, light-weight aluminum components where possible, and corrosion salt spray testing (ISO 9227) for an extremely comprehensive coilover system.
Dual Flow Valve Technology allows the Road&Track improves comfort (figure 1) and maintains tire contact with the road (figure 2) for ideal street and track performance.
A thermal needle bleed valve responds to temperature, expanding when hot as damper fluid loses viscosity. For track guys, this ensures a consistent dampening rate despite changes in damper fluid viscosity.
Light weight aluminum components ensures reduced unsprung weight.
Corrosion salt spray testing (ISO 9227) ensures a rust resistant product guaranteed by Öhlins for two years.
Applications:
- Honda Civic Type R [FK8 ] (2017, 2018, 2019, 2020, 2021)
- Honda Civic Type R [FL5 ] (2023, 2024, 2025)
FEATURES
- Incorporates Original OE upper mounts.
- Cancellation Kit Available.
- DFV (Dual Flow Valve) Technology for constant high/low speed compression
- Thermal expanding needle bleed valve to maintain consistant dampening
- Light-weight aluminum components where possible to reduce unsprung weight
- Corrosion salt spray testing (ISO 9227) for durability
- 2 year limited warranty
- Made in Sweden
EXTENDED INFORMATION
- Shock Design: Inverted Monotube
- Dampening Adjustable: 34-Way
- Rebuildable: Yes
- Spring Rate (front / rear): 60 / 100 [N/mm]
- Spring Rate (front / rear): 6.1 / 10.2 [kgf/mm]
- Springs Diameter: 65 [mm]
- Spring Length (front / rear): NA
- Pillowball Top Mount: No
- Camber Plate: No
- Recommended Preload: 200 / 160 [N] or 2 [mm] front & rear
- Height (front / rear): 20 / 20 [mm] (with Ohlins recommended specs)
- Warranty: Two Year
